$46.00
Availability: 214 in stock
Free Shipping |
LithiumHub 30 Day Return Policy |
| Model | IC-16V6-CHP |
|---|---|
| Voltage | 16V |
| Charger Type | Single Voltage |
| Number of Banks | 1 |
| Max Charge Current | 6A |
| Input Type | AC Mains |
| Input Voltage Range | 110V 60Hz |
| Bluetooth | No |
| Compatible Battery Chemistry | Lead-Acid, LiFePO4 |
| Compatible With | Kayak, Marine |
| Max Charge Voltage | 18.25V |
| Charging Mode | Smart charging — constant current → constant voltage → automatic shutoff at full |
| Auto-Stop at Full | Yes — automatically stops charging once battery reaches full to protect battery life |
| Charge Time Example | 16V 52Ah → ~8.5 hours |
| LED Status Indicators | Green On = Fully Charged, Red On = Charging, Red Flash = Fault |
| Connection Type | Alligator clips (red + / black –) |
| Parallel Wiring | Multiple units can be wired in parallel to increase combined charging current for larger 16V banks |
| Compatible Configurations | Individual 16V battery OR multiple 16V batteries in parallel — NOT for series configurations beyond 16V |
| Cooling Method | Passive |
| Charging Stages | Three-stage (CC bulk → CV absorption → automatic cutoff) |
| Weight | 2 lbs (0.91 kg) |
| Dimensions | 7.5" (L) × 5" (W) × 2.7" (H) 191x127x69 mm |
It’s made for Ionic 16V lithium batteries up to 52Ah — including the 16V 52Ah deep-cycle sonar/forward-facing-sonar battery — and it also works with 16V lead-acid batteries. It charges individual 16V batteries or multiple 16V batteries wired in parallel.
About 8.5 hours for a full charge from the 6A output. It delivers constant current and voltage, then automatically stops at full to protect the battery.
The LED shows status at a glance: solid green means fully charged, solid red means charging, and a flashing red light indicates a fault. If you see a flashing red light, disconnect and check your connections and battery.
No — it’s a smart charger that automatically stops charging once the battery reaches full (around 18V), which helps maximize the life of your lithium battery.
Yes — you can wire this charger in parallel to add charging current to larger 16V systems. It’s designed for individual 16V lithium batteries and 16V batteries connected in parallel.
