These chargers are constant current, constant voltage (CCCV) “Smart” chargers for 24V LiFePO batteries. “Smart” chargers stop charging once 29.2V is reached.
For safety reasons, the charger times out and stops charging after 72 hours of continuous use. That is indicated by blinking red LEDs. To activate the charger again, simply disconnect and reconnect the power cable.
$169.00
Availability: 675 in stock
These chargers are constant current, constant voltage (CCCV) “Smart” chargers for 24V LiFePO batteries. “Smart” chargers stop charging once 29.2V is reached.
For safety reasons, the charger times out and stops charging after 72 hours of continuous use. That is indicated by blinking red LEDs. To activate the charger again, simply disconnect and reconnect the power cable.
Free Shipping |
LithiumHub 30 Day Return Policy |
| Model | IC-24V10-CHP |
|---|---|
| Voltage | 24V |
| Charger Type | Single Voltage |
| Number of Banks | 1 |
| Max Charge Current | 10A |
| Input Type | AC Mains |
| Input Voltage Range | 110–240V AC, 50/60Hz |
| Bluetooth | Yes |
| Compatible Battery Chemistry | LiFePO4 |
| Compatible With | Marine, Trolling Motor |
| Max Charge Voltage | 29.2V |
| Charging Mode | Constant Current → Constant Voltage (CCCV) — smart charger with automatic shutoff at 29.2V |
| Auto-Stop at Full | Yes — stops charging once 29.2V is reached |
| Charge Time Example | 24V 50Ah → ~5 hours full from empty |
| LED Status | Green LED = Charge Complete, Red LED = Charging |
| 72-Hour Safety Auto-Stop | Yes (blinking red LEDs indicate timeout; disconnect and reconnect power to restart) |
| Parallel Wiring | Multiple units can be wired in parallel to increase combined charging current for larger 24V banks |
| Cooling | Passive |
| Weight | 3.10 lbs (1.41 kg) |
| Dimensions | 5.2" (L) × 2.2" (W) × 1.1" (H) 132x56x28 mm |
It’s a 24V smart charger for Ionic 24V lithium batteries — like the 24V 50Ah deep-cycle/trolling battery — and it can charge an individual 24V battery or multiple 24V batteries wired in parallel.
About 2–3 hours for a full recharge at 10A — owners report topping up a 24V 50Ah trolling battery in that time after a full day on the water. It uses a constant-current/constant-voltage (CCCV) profile and stops at 29.2V when full.
No — it’s a smart charger that automatically stops once the battery reaches a full 29.2V. As an added safety measure it also times out after 72 hours of continuous charging (shown by blinking red LEDs); to restart, simply disconnect and reconnect the power cable.
Yes — it’s designed for individual 24V batteries and for 24V batteries connected in parallel, and it can be wired in parallel to add charging current to larger 24V systems.
Yes — it accepts a wide 110V–240V AC input at 50/60Hz, so it works on both North American and international mains power, which suits travel and export use.
